Description
Frameset
-
Frame800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, IsoFlow seat tube, invisible cable routing, 3S aero chain keeper, T47 BB, flat mount disc, 142x12mm thru axle
-
ForkMadone KVF full carbon, tapered carbon steerer, internal brake routing, flat mount disc, carbon dropouts, 12x100mm thru axle
Wheels
-
WheelsBontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready
-
TiresBontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25c
Drivetrain
-
ChainShimano Ultegra/XT M8100, 12 speed
-
CrankSize: 47, Shimano Ultegra R8100, 52/36, 165mm length; Size: 50, 52, Shimano Ultegra R8100, 52/36, 170mm length; Size: 54, 56, 58, Shimano Ultegra R8100, 52/36, 172.5mm length; Size: 60, 62, Shimano Ultegra R8100, 52/36, 175mm length
-
Bottom BracketPraxis, T47 threaded, internal bearing
-
Front DerailleurShimano Ultegra R8150 Di2, braze-on, down swing
-
Rear DerailleurShimano Ultegra R8150 Di2, 34T max cog
-
ShiftersShimano Ultegra R8170 Di2, 12 speed
Components
-
BrakesetShimano Ultegra hydraulic disc, BR-R8170 flat mount caliper, resin pad w/fin
-
SaddleSize: 47, 50, 52, Bontrager Aeolus P2 Elite, 155mm width; Size: 54, 56, 58, 60, 62, Bontrager Aeolus Elite, austenite rails, 145mm width
-
SeatpostSize: 47, 50, 52, 54, Madone aero carbon internal seatmast cap, integrated light mount, 0mm offset, short length; Size: 56, 58, 60, 62, Madone aero carbon internal seatmast cap, integrated light mount, 0mm offset, tall length
