Available sizes
48cm, 51cm, 54cm, 56cm, 58cm, 61cm
Fork
Cervélo all-carbon, Bayonet S5 model
Headset
FSA IS2: top 1-1/8 (36° x 45°) / bottom 1-3/8 (36° x 45°)
Seat post
Cervélo SP34 carbon
Saddle
Selle Italia Novus Boost EVO SuperFlow saddle with titanium rails
Front derailleur
Shimano Ultegra Di2 R8150
Rear derailleur
Shimano Ultegra Di2 R8150
Cassette
Shimano Ultegra R8100, 11-34 teeth, 12 speed
Chain
Shimano M8100
Crankset
Shimano Ultegra R8100, 52/36 teeth, with 4iiii Precision Pro GEN3+ power meter (dual measurement)
Bottom bracket
FSA threaded BBright for 24mm axle
Tires
Vittoria Corsa Pro TLR G2.0 700 x 29c
Maximum tire width
34 mm (measured)
Accessories supplied
- Front mount for computer or accessory (Cervélo Computer Mount 887)
- Cervélo Rear Accessory Mount
One-piece handlebar and stem
Cervélo HB19 Carbon with “Plus-Four” geometry
Hanger width by size
- 48 cm : 36 cm
- 51 cm : 38 cm
- 54 cm : 40 cm
- 56 cm : 40 cm
- 58 cm : 40 cm
- 61 cm : 40 cm
Stem length depending on size
- 48 cm: 80 mm
- 51 cm: 90 mm
- 54 cm: 100 mm
- 56 cm: 100 mm
- 58 cm: 110 mm
- 61 cm: 120 mm
Seatpost offset by size
- 48 cm: 0 mm
- 51 cm: 0 mm
- 54 cm: 0 mm
- 56 cm: 0 mm
- 58 cm: 15 mm
- 61 cm: 15 mm
Front thru axle
Cervélo Aero Thru Axle, M12 x 1.5mm, 122mm Length
Rear thru axle
Cervélo Aero Thru Axle, M12 x 1.0 mm, length 169 mm
Front wheel
Reserve 57TA, DT Swiss 240 hub, 12 x 100 mm, 24 spokes, centerlock mounting, tubeless compatible
Rear wheel
Reserve 64TA, DT Swiss 240 hub, 12 x 142 mm, HG freehub body, 24 spokes, centerlock mount, tubeless compatible
Gear levers / brakes
Shimano Ultegra R8170, with hydraulic disc brake
Crank length depending on size
- 48 cm: 165 mm
- 51 cm: 165 mm
- 54 cm: 170 mm
- 56 cm: 170 mm
- 58 cm: 172.5 mm
- 61 cm: 172.5 mm
Brake discs
Shimano CL800, centerlock mount
