Description
Connected performance with the AXS sensor
Zipp equips the 303 SW rim with the internally integrated Zipp AXS Wheel Sensor. This system analyzes and monitors tire pressure in real time, helping optimize performance in a variety of riding environments. Before each ride, a green light indicates whether the pressure is adequate. While riding, the rider can monitor pressure changes to adjust settings or detect problems quickly.
Aerodynamic and comfortable design
The 40mm deep rim profile is inspired by the Zipp 303 XPLR gravel model. It adopts a wide shape, designed to improve aerodynamics while reducing rolling resistance. This design promotes a smooth transition between the rim and wider tires, optimizing speed and comfort on rough or uneven roads.
Thanks to reduced tire deformation and better vibration absorption, this rim-tire system limits rider fatigue. The combination of a larger tire, lower pressure, and increased air volume allows for a smoother and more efficient ride.
Improved robustness and modern compatibility
The Zipp 303 SW wheels ‘ carbon structure has been reworked to improve impact resistance by nearly 10%, while maintaining a low weight. The model is optimized for 30-35mm tires. The rim shape effectively protects the tires in the event of an impact that could cause a pinch flat.
The ZR1 hub, positioned in the center of the wheels, is now equipped with stainless steel bearings for increased durability and a smoother ride.
Main features
- Versatile wheels designed for road and mountain bikers
- First connected wheel integrating the Zipp AXS Wheel Sensor
- ZR1 hub with stainless steel bearings
- TSE technology for enhanced efficiency and low rolling resistance
- Optimized for 30-35mm wide tires
- Center Lock Disc Brake Interface (lockring included)
- Compatible with XDR or SRAM / Shimano freewheel bodies
- Campagnolo freewheel body sold separately
- Lifetime warranty offered by the Zipp brand
Model
Manufacturer Part Number: WH-303-SW-A1
Technical specifications
- Wheel size: 700c
- Rim construction: Carbon – hookless
- Tire Compatibility: ISO/TSS compatible tubeless tires (30-44c) with inner tube or sealant
- Rim depth: 40 mm
- Brake compatibility: Disc brake (Center Lock)
- Internal rim width: 25 mm
- Rim profile: Symmetrical
- Rim finish: UD fiber, adhesive decals
- Hub: ZR1 Disc Brake
- Freehub Body Type: SRAM XDR, SRAM / Shimano Road
- Bearings: Cartridge – Stainless steel
- Maximum tire pressure: 73 psi / 5.0 bar
- Maximum recommended system weight: 120 kg (265 lbs)
- Spoke length on the transmission side: 272 mm, 274 mm
- Length of spokes on the opposite side: 276 mm
- Weight: 1440g (lightest configuration with 12mm thru axles and XDR body, rim tape and valve included)
SRAM AXS Sensor LED Indications
- Green light: Tire pressure is correct. You’re ready to roll!
- Slowly flashing red light: Low pressure detected. It may be time to reinflate a little.
- Fast flashing red light: Pressure too high detected. Consider releasing some air.
SRAM AXS Application Connectivity
- Compatible with Hammerhead, Garmin & Wahoo computers
SRAM AXS sensor power supply
- The SRAM AXS sensor included in the rim works with a CR2032 battery (can be replaced without removing the valve)
